Available Steel Tubing Sizes
Imperial Steel manufactures quality steel tubing in a range of steel tubing sizes for a variety of industrial applications. Available wall thicknesses and finishes allow customers to select tubing that meets their specific requirements. The chart below provides weight-per-foot information for available tubing sizes by outside diameter and wall thickness.
| Outside Diameter | Wall Thickness (in.) | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0.065 | 0.083 | 0.089 | 0.109 | 0.119 | 0.134 | 0.150 | 0.165 | 0.179 | |
| 3.000″ O.D. | 2.04 | 2.59 | 2.95 | 3.37 | 3.69 | 4.1 | – | – | – |
| 3.500″ O.D. | 2.39 | 3.03 | 3.46 | 3.95 | 4.33 | 4.82 | – | – | – |
| 4.000″ O.D. | 2.73 | 3.47 | 3.96 | 4.53 | 4.94 | 5.53 | – | – | – |
| 5.000″ O.D. | 3.43 | 4.36 | 4.98 | 5.7 | 6.25 | 6.96 | – | – | – |
| 6.000″ O.D. | 4.12 | 5.25 | 5.99 | 6.86 | 7.54 | 8.4 | – | – | – |
| 7.000″ O.D. | 4.81 | 6.13 | 7.006 | 8.02 | 8.82 | 9.83 | – | – | – |
| 8.000″ O.D. | – | 7.02 | 8.02 | 9.19 | 10.1 | 11.26 | – | – | – |
| 8.500″ O.D. | – | 7.46 | 8.3 | 9.6 | 10.74 | 12.5 | – | – | – |
| 10.000″ O.D. | – | 8.79 | 10.05 | 11.52 | 12.66 | 14.12 | – | – | – |
| 12.000″ O.D. | – | – | – | 13.84 | 15.23 | 16.98 | 18.98 | 20.86 | 22.72 |
| 12.750″ O.D. | – | – | – | 14.72 | 16.19 | 18.06 | 20.19 | 22.18 | 24.16 |
| 14.000″ O.D. | – | – | – | 14.72 | 16.19 | 18.06 | 21.895 | 24.38 | 26.568 |
- 10′ – 52′ lengths
- Cut-to-length options
- Tight tolerances
- Custom steel tubing sizes
3" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 3" od x .065 tubing 20′ | 2.04 | 22 pcs | 50 |
| 3" od x .083 tubing 20′ | 2.59 | 22 pcs | 39 |
| 3" od x .109 tubing 20′ | 3.37 | 22 pcs | 30 |
| 3" od x .119 tubing 20′ | 3.69 | 22 pcs | 27 |
| 3" od x .135 tubing 20′ | 4.10 | 22 pcs | 24 |
3.5" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 3.5" od x .065 tubing 20′ | 2.39 | 22 pcs | 40 |
| 3.5" od x .083 tubing 20′ | 3.03 | 22 pcs | 33 |
| 3.5" od x .109 tubing 20′ | 3.95 | 22 pcs | 25 |
| 3.5" od x .119 tubing 20′ | 4.33 | 22 pcs | 23 |
| 3.5" od x .135 tubing 20′ | 4.82 | 22 pcs | 21 |
4" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 4" od x .065 tubing 20′ | 2.73 | 22 pcs | 32 |
| 4" od x .083 tubing 20′ | 3.47 | 22 pcs | 29 |
| 4" od x .109 tubing 20′ | 4.53 | 22 pcs | 22 |
| 4" od x .119 tubing 20′ | 4.94 | 22 pcs | 20 |
| 4" od x .135 tubing 20′ | 5.53 | 22 pcs | 18 |
4.5" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 4.5" od x .065 tubing 20′ | 3.08 | 22 pcs | 32 |
| 4.5" od x .083 tubing 20′ | 3.92 | 22 pcs | 26 |
| 4.5" od x .109 tubing 20′ | 5.11 | 22 pcs | 20 |
| 4.5" od x .119 tubing 20′ | 5.61 | 22 pcs | 18 |
| 4.5" od x .135 tubing 20′ | 6.25 | 22 pcs | 16 |
5" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 5" od x .065 tubing 20′ | 3.43 | 10 pcs | 40 |
| 5" od x .083 tubing 20′ | 4.36 | 10 pcs | 40 |
| 5" od x .109 tubing 20′ | 5.70 | 10 pcs | 39 |
| 5" od x .119 tubing 20′ | 6.25 | 10 pcs | 36 |
| 5" od x .135 tubing 20′ | 6.96 | 10 pcs | 32 |
6" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 6" od x .065 tubing 20′ | 4.12 | 10 pcs | 40 |
| 6" od x .083 tubing 20′ | 5.25 | 10 pcs | 40 |
| 6" od x .109 tubing 20′ | 6.86 | 10 pcs | 32 |
| 6" od x .119 tubing 20′ | 7.54 | 10 pcs | 29 |
| 6" od x .135 tubing 20′ | 8.40 | 10 pcs | 26 |
6.625" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 6.625" od x .065 tubing 20′ | 4.55 | 16 pcs | 24 |
| 6.625" od x .083 tubing 20′ | 5.80 | 16 pcs | 24 |
| 6.625" od x .109 tubing 20′ | 7.59 | 16 pcs | 18 |
| 6.625" od x .119 tubing 20′ | 8.34 | 16 pcs | 16 |
| 6.625" od x .135 tubing 20′ | 9.29 | 16 pcs | 15 |
7" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 7" od x .065 tubing 20′ | 4.81 | 10 pcs | 24 |
| 7" od x .083 tubing 20′ | 6.13 | 10 pcs | 24 |
| 7" od x .109 tubing 20′ | 8.02 | 10 pcs | 24 |
| 7" od x .119 tubing 20′ | 8.82 | 10 pcs | 24 |
| 7" od x .135 tubing 20′ | 9.83 | 10 pcs | 22 |
8" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 8" od x .083 tubing 20′ | 7.02 | 10 pcs | 24 |
| 8" od x .109 tubing 20′ | 9.19 | 10 pcs | 24 |
| 8" od x .119 tubing 20′ | 10.10 | 10 pcs | 22 |
| 8" od x .135 tubing 20′ | 11.26 | 10 pcs | 19 |
8.625" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 8.625" od x .083 tubing 20′ | 7.57 | 9 pcs | 18 |
| 8.625" od x .109 tubing 20′ | 9.93 | 9 pcs | 18 |
| 8.625" od x .119 tubing 20′ | 10.90 | 9 pcs | 18 |
| 8.625" od x .135 tubing 20′ | 12.24 | 9 pcs | 18 |
10" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 10" od x .083 tubing 20′ | 8.79 | 8 pcs | 18 |
| 10" od x .109 tubing 20′ | 11.52 | 8 pcs | 18 |
| 10" od x .119 tubing 20′ | 12.66 | 8 pcs | 18 |
| 10" od x .135 tubing 20′ | 14.12 | 8 pcs | 18 |
12" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 12" od x .150 tubing 20′ | 18.98 | 4 pcs | 24 |
| 12" od x .165 tubing 20′ | 20.86 | 4 pcs | 24 |
| 12" od x .179 tubing 20′ | 22.72 | 4 pcs | 24 |
12.75" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 12.75" od x .150 tubing 20′ | 20.19 | 4 pcs | 18 |
| 12.75" od x .165 tubing 20′ | 22.18 | 4 pcs | 18 |
| 12.75" od x .179 tubing 20′ | 24.16 | 4 pcs | 18 |
14" OD
| Description | WPF | Pieces per Load | Bundles per Load |
|---|---|---|---|
| 14" od x .105 tubing 20′ | 16.17 | 4 pcs | 18 |
| 14" od x .119 tubing 20′ | 17.79 | 4 pcs | 18 |
| 14" od x .135 tubing 20′ | 19.84 | 4 pcs | 18 |
| 14" od x .150 tubing 20′ | 21.90 | 4 pcs | 18 |
| 14" od x .165 tubing 20′ | 24.38 | 4 pcs | 18 |
| 14" od x .179 tubing 20′ | 26.57 | 4 pcs | 18 |
- Based on full loads on Aat deck trailers
- These are general load sizes
- Bundle Quantities only no modifications
Need a specific steel tubing size or specification? Learn more about our capabilities or contact our team to discuss your requirements.
